Specification:
Type | DCL-Ex10 | ||||
| DC24V | AC24V | AC110V | AC380V | AC220V | |
| Motor Power | 25W | 25W | 25W | 15W | 25W |
| Rated Current | 2.20A | 2.12A | 0.57A | 0.10A | 0.30A |
| Standard Time/Torque | 30S/100Nm | ||||
| Optional Time/Torque | 15S/50Nm | 15S/50Nm 60S/100Nm | |||
| Turning Angle | 0～900 Adjustable | ||||
| Available Control Circuit | Type of A,B,C,D,E,F,G,H, | ||||
| Total Weight | 5kg | ||||
| Insulating Resistance | 100MΩ/250VDC | 100MΩ/500VDC | |||
| Withstand Voltage Class | DC24V/AC24V: 500VAC 1 minute,AC110V/AC220V: 1500VAC 1 minute,AC380V: 1800VAC 1 minute | ||||
| Protection Class | IP68 | ||||
| Expiosive-proof grade | ExⅡCT4Gb | ||||
| Installation Angle | 3600 at any angle | ||||
| Electric Interface | 2-M20×1.5explosion-proof plug,clients should install corresponding explosion-proof cable connector when using according to the cable selected. | ||||
| Ambient Temperature | -20～+60℃ | ||||
| Optional Function | Over-torque Protector/Heater | ||||
| Type | DCL-Ex20 | |||
| DC24V | AC110V | AC380V | AC220V | |
| Motor Power | 25W | 40W | 30W | 40W |
| Rated Current | 3.12A | 0.63A | 0.19A | 0.35A |
| Standard Time/Torque | 60S/200Nm | 30S/200Nm | ||
| Optional Time/Torque | 30S/100Nm | 15S/100Nm | 15S/100Nm 60S/200Nm | |
| Turning Angle | 0～900 Adjustable | |||
| Available Control Circuit | Type of A,B,C,D,E,F,G,H, | |||
| Total Weight | 5.5kg | |||
| Insulating Resistance | 100MΩ/250VDC | 100MΩ/500VDC | ||
| Withstand Voltage Class | DC24V: 500VAC 1 minute,AC110V/AC220V: 1500VAC 1 minute,AC380V: 1800VAC 1 minute | |||
| Protection Class | IP67 | |||
| Expiosive-proof grade | ExⅡCT4Gb | |||
| Installation Angle | 3600 at any angle | |||
| Electric Interface | 2-M20×1.5explosion-proof plug,clients should install correspondingexplosion-proof cable connector when using according to the cable selected. | |||
| Ambient Temperature | ’-20～+60℃ | |||
| Optional Function | Over-torque Protector/Heater | |||
